Number of inputs and outputs

Number of digital outputs: 2

Output signal

Switching signal; IO-Link

Electrical design

PNP/NPN

Output function

Normally open / normally closed; (parameterisable)

Max. voltage drop switching output DC [V]

2.5

Permanent current rating of switching output DC [mA]

100

Short-circuit protection

Yes

Type of short-circuit protection

Pulsed

Overload protection

Yes

Media

Oils; oil-based media; liquids; viscous media; powder

Probe length [mm]

11

Tank pressure [bar]

-1...40

Oil, Water:

Medium temperature [°C]

-40...100

Medium temperature short time [°C]

-40...150; (1 h)

Operating voltage [V]

18...30 DC

Current consumption [mA]

< 50

Protection class

III

Reverse polarity protection

Yes

Ambient temperature [°C]

-40...85

Storage temperature [°C]

-40...85

Protection

IP 68; IP 69K

Weight [g]

210

Materials

Stainless steel (1.4404 / 316L); PEEK; PEI; FKM

Materials (wetted parts)

PEEK

Process connection

G 1/2 external thread

Display

Switching status

LEDs, yellow

Operating status

LEDs, green

Connection

Connector: 1 x M12; Contacts: gold-plated
