Model | J4125 |
Processor | CPU | Intel Celeron J4125 (4 core 4 threads, 4M Cache, 2.00GHz, up to 2.70GHz, TDP: 10W) |
Graphics Card | Integrated | J4125: Intel UHD Graphics 600 Graphics Base Frequency: 250MHz Graphics Max Dynamic Frequency: 750MHz DirectX* Support:12 |
Memory | Technique | 1* Single Channel SODIMM, support DDR4 only |
Max Ram | 8GB |
Socket | 1*204-pin SO-DIMM |
Display | VGA | Max Resolution 1920×1080@60Hz |
HDMI | Max Resolution 4096x2160@30Hz(J4125), support 4K. |
Dual Display | VGA+HDMI, Support for Synchronous or Independent display |
Ethernet | LAN | 2*RJ45 10/100/1000/ Mbps Realtek 8111F Supports Wake UP on LAN, S5 RTC Wake Settings, PXE Boot, Restore AC power loss. |
Audio | Main System | Adopting Realtek ALC662 Chip, Supports dual channels, stereo, and Line out |
I/O | COM | 2*RS232 |
USB | 2* USB3.0 2*USB2.0 |
Other | Watchdog Timer | Supports (If you need this hardware, please let us know before payment) |
WIFI | WIFI module | with dual antennas,300M,802.11.b/g/n |
Extension | Mini-PCIe | 1* Half Height Mini PCIe |
Storage | HDD | 1*2.5” HDD SATA(Highest data conversion rate SATA2.0) |
SSD | 1*Full size mSATA Socket |
Software | OS | Windows 8/ Windows 10/ Linux/ Ubuntu/ Centos etc. |
Cooling System | Fanless | Fanless Passive cooling with Heat Sink Aluminum Block |
Power Consumption | Power Type | DC-IN5.5*2.5 |
Power Adapter | DC 12V5A/ 60W (AC TO DC, 100~ 240V) |
TDP | 7.5-15W |
Physical Characteristics | Case material | Aluminum Alloy |
Installation | VESA/Wall/Desktop |
Dimensions | 133*125*40mm |
Weight | 1.5 KG |
Environment | Operating temperature | -20℃~ 65℃ |
Storage temperature | -20℃~ 85℃ (15- 35℃ recommended) |
Operating humidity | 5%-95% Relative humidity, no condensation |
