Number of inputs and outputs

Number of digital outputs: 1; Number of analogue outputs: 1

Media

Liquids; oil-based media; hydrous media

Dielectric constant of the medium

≥ 1,8; (for media with a dielectric constant of 1.8...5 (e.g. oils), a coaxial pipe is

 needed for operation)

Recommended media

Water; hydrous media; oils; oil-based media

Medium temperature [°C]

-20...100

Tank pressure [bar]

-1...16

Operating voltage [V]

18...30 DC

Current consumption [mA]

< 50

Protection class

III

Reverse polarity protection

Yes

Power-on delay time [s]

< 3

Output signal

Switching signal; analogue signal; IO-Link

Electrical design

PNP/NPN

Number of digital outputs

1

Output function

Normally open / normally closed; (parameterisable)

Max. voltage drop switching output DC [V]

2.5

Permanent current rating of switching output DC [mA]

150; (200 (...60 °C))

Number of analogue outputs

1

Analogue current output [mA]

4...20, invertible; (scalable)

Short-circuit protection

Yes

Type of short-circuit protection

Pulsed

Overload protection

Yes

Probe length L [mm]

150...2000

Hysteresis [mm]

> 5

Ambient temperature [°C]

-40...80

Storage temperature [°C]

-40...100

Protection

IP 68; IP 69K

Weight [g]

447.5

Materials

Stainless steel (1.4404 / 316L); PEI; PFA; PBT; FKM

Materials (wetted parts)

Stainless steel (1.4404 / 316L); stainless steel (1.4435 / 316L); PTFE; FKM

Display

Display unit

3 x LED, green

Switching status

2 x LED, yellow

Level

Alphanumeric display, 4-digit

Parameter setting

Alphanumeric display, 4-digit

Process connection

G 3/4 external thread

Connection

Connector: 1 x M12; Contacts: gold-plated
