Cảm biến mức

Cảm biến mức (25 Sản phẩm)

HOT

5,386,017 ₫

Number of inputs and outputs			Number of digital outputs: 2
Output signal			Switching signal; IO-Link
Electrical design			PNP/NPN
Output function			Normally open / normally closed; (parameterisable)
Max. voltage drop switching output DC [V]			2.5
Permanent current rating of switching output DC [mA]			100
Short-circuit protection			Yes
Type of short-circuit protection			Pulsed
Overload protection			Yes
Media			Hydrous media; liquids; viscous media; powder
Probe length [mm]			11
Tank pressure [bar]			-1...40
Oil, Water		Medium temperature [°C]	-40...100
		Medium temperature short time [°C]	-40...150; (1 h)
Operating voltage [V]			18...30 DC
Current consumption [mA]			< 50
Protection class			III
Reverse polarity protection			Yes
Ambient temperature [°C]			-40...85
Note on ambient temperature: Medium temperature			< 150 °C
Storage temperature [°C]			-40...85
Protection			IP 68; IP 69K
Weight [g]			208.5
Materials			Stainless steel (1.4404 / 316L); PEEK; PEI; FKM
Materials (wetted parts)			PEEK
Process connection			G 1/2 external thread
Surface characteristics Ra/Rz of the wetted parts			< 0.8
Display	Switching status		LEDs, yellow
	Operating status		LEDs, green
Connection			Connector: 1 x M12; Contacts: gold-plated
